型號 Item no. | 扭力 Torque | 扭力 Torque | 扭力 Torque | 精度 Repeatable Torque Accuracy | 空轉速 | 空轉速 | 螺絲直徑 機械牙 Machine Screw | 螺絲直徑 自攻牙 Tapping Screw | 重量Weight | 長度 |
(kgf.cm) | (Lbf.in) | (N.m) | (%) | (r.p.m) | (r.p.m) | (mm) | (mm) | (g) | (mm) | |
SKD-B100L | 0.08~1.5 | 0.07~1.33 | 0.008~0.15 | ±5% | 1000 | 700 | 1.0~1.7 | 1.0~1.5 | 170 | 165 |
SKD-B103L | 0.5~3.5 | 0.44~3.01 | 0.05~0.34 | ±5% | 1000 | 700 | 1.0~2.3 | 1.0~2.0 | 170 | 165 |
SKD-B100LS4 | 0.08~1.5 | 0.07~1.33 | 0.008~0.15 | ±5% | 280 | 200 | 1.0~1.7 | 1.0~1.5 | 170 | 165 |
SKD-B103LS4 | 0.5~3.5 | 0.44~3.01 | 0.05~0.34 | ±5% | 280 | 200 | 1.0~2.3 | 1.0~2.0 | 170 | 165 |
型號 Item no. | 扭力 Torque | 扭力 Torque | 扭力 Torque | 精度 Repeatable Torque Accuracy | 空轉速 | 空轉速 | 螺絲直徑 機械牙 Machine Screw | 螺絲直徑 自攻牙 Tapping Screw | 重量Weight | 長度 |
(kgf.cm) | (Lbf.in) | (N.m) | (%) | (r.p.m) | (r.p.m) | (mm) | (mm) | (g) | (mm) | |
SKD-B100L | 0.08~1.5 | 0.07~1.33 | 0.008~0.15 | ±5% | 1000 | 700 | 1.0~1.7 | 1.0~1.5 | 170 | 165 |
SKD-B103L | 0.5~3.5 | 0.44~3.01 | 0.05~0.34 | ±5% | 1000 | 700 | 1.0~2.3 | 1.0~2.0 | 170 | 165 |
SKD-B100LS4 | 0.08~1.5 | 0.07~1.33 | 0.008~0.15 | ±5% | 280 | 200 | 1.0~1.7 | 1.0~1.5 | 170 | 165 |
SKD-B103LS4 | 0.5~3.5 | 0.44~3.01 | 0.05~0.34 | ±5% | 280 | 200 | 1.0~2.3 | 1.0~2.0 | 170 | 165 |
